Battery Testing Services
Solid UltraBattery provides single-cell battery testing services for coin, pouch, cylindrical, and prismatic cells, helping customers evaluate performance, durability, and behavior across a wide range of operating conditions.
Cycle Life
Constant current/power charge-discharge
Constant voltage charge-discharge
Calendar Life and Accelerated Aging
Battery testing at variable temperatures (0 to 60°C)
Battery Kinetics
C-rate test
Hybrid pulse power characteristics (HPPC)
Extreme Low Temperature Performance
Battery testing at temperatures down to -70°
Battery Data Reporting
Data plots (Charge-discharge curves, capacity retention, C-rate retention, etc.)
Battery Testing Equipment
The table below details Solid UltraBattery's single-cell battery testers, including current ranges, channel availability, and accuracy for each cell type.
Current ranges listed are equipment specifications, not exclusive requirements; higher capacities (e.g., 6A, 20A, 50A) can be used for pouch, cylindrical, or prismatic cells depending on the specific battery's size and testing needs.
Tester | Current Range | Availability | Accuracy |
|---|---|---|---|
Coin | 0.05mA to 10mA | 160 Channels | ± 0.05% of FS
(1mA, 5mA, and 10mA) |
Pouch | 0.5mA to 6A | 160 Channels | ± 0.05% of FS
(100mA, 3A, and 6A) |
Cylindrical | 0.1A to 20A | 24 Channels | ± 0.1% of FS |
Prismatic | 0.25A to 50A | 32 Channels | ± 0.1% of FS |
Battery Testing Chambers
Constant Temperature Incubator
- Temperature range between 0 to 60°C
- Availability: All channels
Low Temperature Chamber
- Temperature range between -70 to 180°C
- Availability: Limited channels
Request a Quote
